Key performance features
- Energy Efficiency Class: A
- Extraction rate according to EN 61591 ø 15 cm:
- max. Normal use 420 m/h
- Intensive 680 m/h
- Noise max. Normal Level: 57 dB
Features
- Touch control
- LED display
- 3 speeds plus intensive
- 2 x 1.5w LED Light
- Colour Temperature: 3500 K
- Automatic intensive revert (6mins)
- 2 metal grease filter cassettes
- Easy to clean Inner frame
- For wall mounted installation
- Rim ventilation
Design
- Black
- Angled glass design
- Chimney hood
- Touch control
- Electronic controls
Performance/technical information
- Suitable for ducted extraction and recirculation
- For recirculated extraction recirculating kit or CleanAir recirculating kit (accessory) needed
- Easy installation system
- Extraction rate according to EN 61591 ø 15 cm:
- max. Normal use 420 m/h
- Intensive 680 m/h
- Extraction rate according to EN 61591 max. 420 m/h
- Noise level according to EN 60704-3 and EN 60704-2-13 at max. normal use exhaust air: 57 dB(A) re 1 pW (43 dB(A) re 20 µPa sound pressure)
- Noise level according to EN 60704-3 and EN 60704-2-13 exhaust air:
- Max. normal use: 57 dB(A) re 1 pW (43 dB(A) re 20 µPa sound pressure)
- Intensive: 66 dB(A) re 1 pW (52 dB(A) re 20 µPa sound pressure)
- Noise level according to EN 60704-3 and EN 60704-2-13 at maximum normal setting: extraction rate: 57 dB (A) re 1pW
- Noise max. Normal Level: 57 dB
- Power rating: 263 W
- Light Intensity: 90 lux
- Colour Temperature: 3500 K
- Electrical cable length 1.3 m
- Diameter pipe ø 150 mm (ø 120 mm enclosed)
- Dimensions exhaust air (HxWxD): 928-1198 x 890 x 499 mm
- Dimensions recirculating (HxWxD): 988-1258 x 890 x 499 mm
- Dimensions recirculating with CleanAir module (HxWxD):
- 1118 x 890 x 499 mm – mounting with outer chimney
- 1188-1458 x 890 x 499 mm – mounting with telescopic chimney
- Energy Efficiency Class: A
- Blower Efficiency Class: A
- Lighting Efficiency Class: A
- Grease Filtering Efficiency Class: C
- Average Energy Consumption: 52.8 kWh/year
Optional accessories
- Recirculating kit
