- Key Information
- 3 Speeds
- Maximum Extraction Rate (Normal Use): 620 M³/H
- Maximum Noise Level (Normal Use): 70 dB
- Airflow Range: 255 – 620 M³/H
- Noise Level Range: 50 – 70 dB
- Energy Efficiency Rating: A
- Suitable For Air Extraction Or Recirculation Mode
- Internet Connected Appliance: No
- Design
- Chimney Flue Included: No
- Controls: 3S Mechanical Rotative Control
- Finish: Stainless Steel
- Hood Type: Integrated Hood
- Motor: Internal Motor
- Range: Elica Integrated Hood
- Remote Control Available: No
- Width: 89.4 cm
- Lighting
- Lighting: LED Lighting (2 x 2.5 w)
- Lighting Class: A
- Number Of Lamps: 2
- Features
- Cabinet Protection
- Easy To Maintain
- Long Life Filter
- Total Integration
- Technical Info
- Annual Efficiency Consumption: 55 Kwh/year
- Duct Size: 150 mm
- Fluid Class: A
- Grease Filter Efficiency Class: C
- Minimum Distance From Electric Cooking Top: 50 cm
- Minimum Distance From Gas Cooking Top: 50 cm
- Product Code: BOXIN-LX-BL-90
- Included Accessories
- Aluminium Grease Filter
Call us : 0115 946 2555
Elica BOXIN/LX/BL/90 Built-in Black 550 m³/h
- Built-in 900 mm Black
- 550 m³/h Ducted/Recirculating
- Fluid dynamic efficiency class: A
- Lighting efficiency class: A
- Grease filtering efficiency class: C
- Aluminium/Carbon
- Number of speeds: 3 70 dB
- 2 bulb(s) LED 2.25 W 381 lx
- 55 kWh
SKU : BOXIN/LX/BL/90
Delivery times
If the item is in stock at our warehouse, we will contact you within 24 hours to arrange a delivery date.
If the item is not immediately available, we will contact you within 48 hours via email or phone with an estimated lead time.
Delivery costs
For most orders of £400 and over, delivery is free. For orders under £400, delivery is charged at £30. Please note, a surcharge will apply for some postcodes.
All of our deliveries are manually booked in by phone to ensure a trouble free service.
Full details of our delivery service can be found here.
We will deliver to the ground floor only of your delivery address provided there is unrestricted access to that address. We consider delivery access to be restricted if our delivery drivers are faced with the following:
- Double yellow lines;
- Red routes;
- Narrow lanes;
- Steep hills;
- Low bridges;
- Width restricted roads;
- Property on an upper floor with no lift;
- Basement property via steps; or
- Small lifts.
Specifications
| Overview | |
|---|---|
| Colour | Black |
| Warranty | 2 Years Parts & Labour |
| Design | |
|---|---|
| Type | Built-in |
| Product colour | Black |
| Control type | Rotary |
| Built-in display | |
| Performance | |
|---|---|
| Noise level | 70 dB |
| Hob | |
|---|---|
| Minimum distance from electric hob | 50 cm |
| Minimum distance from gas hob | 60 cm |
| Extraction | |
|---|---|
| Maximum extraction power | 550 m³/h |
| Type of extraction | Ducted/Recirculating |
| Number of speeds | 3 |
| Exhaust connection diameter | 15 cm |
| Grease filter type | Aluminium/Carbon |
| Motor power | 255 W |
| Noise level (low speed) | 50 dB |
| Exhaust location | Top |
| Lighting | |
|---|---|
| Bulb power | 2.25 W |
| Number of bulbs | 2 bulb(s) |
| Bulb type | LED |
| Illuminance | 381 lx |
| Lighting position | Front |
| Energy management | |
|---|---|
| Fluid dynamic efficiency class | A |
| Lighting efficiency class | A |
| Grease filtering efficiency class | C |
| Annual energy consumption | 55 kWh |
| Energy efficiency scale | A+++ to D |
| Energy efficiency class (old) | A |
| Weight & dimensions | |
|---|---|
| Width | 900 mm |
| Depth | 310 mm |
| Height (min) | 3.5 cm |
| Height (max) | 6 cm |
| Installation compartment width | 30.5 cm |
| Installation compartment depth | 27 cm |
| Installation compartment height | 27.9 cm |
